eRob70I Robot Joint Module


Overview

OD70mm robot joint module integrate 8 core components, could help users build robot quickly.

Parameter

Model

                                                                                      eRob70I

Strain wave gear-ratio

14-50

14-80

14-100

14-120

Peak torque for start and stop(Nm)

23

30

36

36

Permissible max.value at average load torque(Nm)

9

14

14

14

Rated torque(Nm)

7

10

10

10

Permissible maximum momentary torque(Nm)

46

61

70

70

Max. output rotational speed(RPM)

60

37.5

30

25

Motor power(W)

100

100

100

100
